CE Certificated Vaccine Blood Products Used Freeze Dryer
Product Description
Model | BK-FD10S | BK-FD10P | BK-FD10T | BK-FD10PT | |||||
Type | Standard chamber | Standard chamber with 8 port manifold | Stoppering chamber | Stoppering 8 port manifold | |||||
Freeze Drying Area | 0.12 m2 | 0.09 m2 | |||||||
Tray | 4 pcs | 3 pcs | |||||||
Height Between Trays | 50mm | 68mm | |||||||
Cold Trap Temperature | ≤-56℃ | ||||||||
Cold Trap Capacity | 9.5L | ||||||||
Cold Trap Size (Diameter*H) | Φ215*260mm | ||||||||
Vacuum Degree | <10 Pa | ||||||||
Water Capture Capacity | 3 Kg/24h | ||||||||
Tray Size (D*H) | Φ200*20mm | Φ180*20mm | |||||||
Freeze Drying Time | 24h | ||||||||
Loading Capacity/Shelf (Liquid) | 0.3L | ||||||||
Total Loading Capacity (Liquid) | 1.2L | 0.9L | |||||||
Drying Chamber Size (Diameter*H) | Φ260*310mm | Φ260*450mm | |||||||
Total Qty. Of Vial Φ22 | 260 | 195 | |||||||
Total Qty. Of Vial Φ16 | 480 | 360 | |||||||
Total Qty. Of Vial Φ12 | 920 | 690 | |||||||
Refrigerant | R600a+R290+R23 | ||||||||
Cooling System | Air cooling | ||||||||
Power Supply | 220V/50Hz,60Hz (single phase) 110V/60Hz (single phase) | ||||||||
Power Consumption | 1.3KW | ||||||||
Standard Accessory | Vacuum Pump 2L/S, 8m3/h (for all models) Conical-mouth flask 500ml*8 pcs (only for model BK-FD10P/PT) | ||||||||
Optional Function & Accessory | Cold trap defrosting Conical-mouth flask and wide-mouth flask(for BK-FD10P/PT) Import vacuum pump | ||||||||
External Size (W*D*H), mm | 640*610*550/810 | 640*610*550/950 | 640*610*550/990 | ||||||
Package Size(W*D*H),mm/Gross Weight | Main Body | 720*705*730(83kg) | |||||||
Drying Chamber /Vacuum Pump | 590*705*530 (40kg) | 590*705*530 (44kg) | 590*705*530 (50kg) | 590*705*530 (53kg) |
8. Drying chamber is transparent which is visual and safe.9. Shelves are stainless steel, which can be adjustable per the requirements.Cold Chain Company InformationCompany InformationBIOBASE Group is specialized in products of 8 areas including medical diagnosis, biosafety protection, disinfection and sterilization, water purification system, infant care products, cold chain products, software products, clean room project. Industry Park Contact Dora Contact us if you need more details on Blood. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Blood、Blood. If these products fail to match your need, please contact us and we would like to provide relevant information.
