BIOBASE Freeze Dryer BK-FD10S Standard Type Tabletop Freeze Dryer

Products Description Tabletop Freeze Dryer INTRODUCE:The lab series freeze dryer is suitable for freeze drying test of laboratory biomedical samples.
Widely used in drugs, biological products, chemical and food industries. On the heat-sensitive substances such as antibiotics, vaccines, blood products, hormones and other biological tissue enzymes, freeze-drying technology is applied.

Model			BK-FD10S	BK-FD10P	BK-FD10T	BK-FD10PT
Type			Standard chamber	Standard chamber with 8 port manifold	Stoppering chamber	Stoppering chamber with 8 port manifold
Freeze Drying Area			0.12 m2			0.09 m2
Tray			4 pcs			3 pcs
Height Between Trays			50mm			68mm
Cold Trap Temperature			≤-56℃
Cold Trap Capacity			9.5L
Cold Trap Size (Diameter*H)			Φ215*260mm
Vacuum Degree			<10 Pa
Water Capture Capacity			3kg/24h
Tray Size (D*H)			Φ200*20mm			Φ180*20mm
Freeze Drying Time			24h
Loading Capacity/Shelf (Liquid)			0.3L
Total Loading Capacity (Liquid)			1.2L			0.9L
Drying Chamber Size (Diameter*H)			Φ260*310mm	Φ260*450mm
Total Qty. Of Vial Φ22			260			195
Total Qty. Of Vial Φ16			480			360
Total Qty. Of Vial Φ12			920			690
Refrigerant			R600a+R290+R23
Cooling System			Air cooling
Power Supply			220V/50Hz,60Hz (single phase) 110V/60Hz (single phase)
Power Consumption			1.3KW
Power Supply			AC220V, 50/60Hz (single phase); 110V, 60Hz (single phase)
Standard Accessory			Vacuum Pump 2L/S, 8m3/h (for all models) Conical-mouth flask 500ml*8 pcs (only for model BK-FD10P/PT)
Optional Function & Accessory			Conical-mouth flask and wide-mouth flask(for BK-FD10P/PT) Import vacuum pump
External Size (W*D*H)			640*610*550/810mm	640*610*550/950mm	640*610*550/990mm
Package Size(W*D*H)mm/ Gross Weight	Main Body	720*705*730(85kg)
		Drying Chamber /Vacuum Pump	705*590*530 (50kg)	705*590*530 (55kg)	705*590*530 (60kg)	720*705*730 (65kg)

Features 1.LCD touch screen.
2. With historical data inquiry function.
3. With USB interface to export the data.
4. Large capacity ice condenser trap and without coil inside.
5. With cascade refrigeration technology.
6. Pre-freezing shelf can be used as guide barrel to speed up the drying rate.
7. Ice condenser trap and operation panel are made by Stainless Steel.
8. Drying chamber is transparent which is visual and safe.
9. Shelves are stainless steel, which can be adjustable per the requirements. Related Products Recommended by sellerBIOBASE Refrigerator BDF-25H358 Horizontal -25 Degree Freezer$700.00 - $900.00 / Unit1.0 UnitsBIOBASE Fume Hood Large Room with Memory Function Walk-in Fume Hood$1,600.00 - $1,700.00 / Unit1.0 Units Packing and Shipping Company Profile Customer Evaluation FAQ 1.Why choose BIOBASE?
